Power Driver Board Continued ...
J130-1 Violet-Brown, solenoid 1 drive to coil
J130-2 Violet-Red, solenoid 2 drive to coil
J130-3 Key
J130-4 Violet-Orange, solenoid 3 drive to coil
J130·S Violet-Yellow, solenoid 4 drive to coil
J130-6 Violet-Green, solenoid 5 drive to coil
J 130-7 Violet-Blue, solenoid 6 drive to coil
J130-8 Violet-Black, solenoid 7 drive to coil
J130-9 Violet-Gray, solenoid 8 drive to coil
J 132- Not Used
J131- Not Used
J 133-Not Used
J134-1 Red-Brown, lamp row 1 to playfield
J 134-2 Red-Black, lamp row 2 to playfield
J134-3 Key
J134-4 Red-Orange, lamp row 3 to playfield
Jt34-S Red-Yellow, lamp row 4 to playfield
J134-6 Red-Green, lamp row 5 to playfield
J134-7 Red-Blue, lamp row 6 to playfield
J134-8 Red-Violet, lamp row 7 to playfield
J134-9 Red-Gray, lamp row 8 to playfield
J135-1
N/C
J135-2
N/C
J135-3 Key
J135-4
N/C
J13S-5
NJC
J13S-6
NJC
J13S-7 Red-Blue, lamp row 6 to cabinet
Jt35-8 Red-Violet, lamp row 7 to cabinet
J135-9 Red-Gray, lamp row 8 to cabinet
Jt36-1 Key
J136-2
N/C
J136-3 Yellow-Gray, lamp column 8 to cabinet
J137- Not Used
J 138-1 Yellow-Brown, lamp column 1 to playfield
J138-2 Yellow-Red, lamp column 2 to playfield
J138-3 Yellow-Orange, lamp column 3 to playfield
J 138-4 Yellow-Black, lamp column 4 to playfield
J138-5 Yellow-Green, lamp column S to playfield
J138-6 Yellow-Blue, lamp column 6 to playfield
J138-7 Yellow-Violet, lamp column 7 to playfield
J138-8 Key
J138-9 Yellow-Gray, lamp column 8 to playfield
3-30
