Power Driver Board Continued ...
J114-1 Gray-Green, +12V to J210-6, 7; J904-2
Jl14-2 Gray-Green, +12V to J210-6, 7; J904-2
Jl14-3 Gray, +5V to J210-4, 5; J3-' ,3; J904-1
J1 14-4 Gray, +5V to J21 0-4, 5; J3-1 ,3; J904-1
J 114-5 B lack, ground to J21 0-1, 3; J3-4, 5; J904-4, 5
J114-6 Key
Jl14-7 Black, ground to J210-1,3; J3-4, 5; J904-4, 5
Jl1S-1 Yellow-White, 6.8Vac from xformer secondary
Jl15·2 White-Brown, 6.8Vac from xformer secondary
J11S-3 White·Brown, 6.8Vac from xformer secondary
J115-4 White-Orange, 6.8Vac from xformer secondary
Jl1S-S White-Yellow, 6.8Vac from xformer secondary
J115-6 White-Yellow, 6.8Vac from xformer secondary
J115-7 Orange, 6.8Vac from xform er secondary
J11S-8 Orange, 6.8Vac from xformer secondary
J115-9 Key
Jl15-1O Green, 6.8Vac from xformer secondary
Jl15·11 Brown, 6.8Vac from xformer secondary
JllS-12 Brown, 6.8Vac from xformer secondary
Jl16-1 Key
Jl16-2 Gray-YellOW, +12V to Coin Door Board J2-2
J116-3 Black, ground to Coin Door Board J2-1
Jl16-4
N/C
J117-1 Key
J117-2 Gray-Yellow, +12V to Dot Matrix Cntrllr J606-7
J117-3 Black, ground to Dot Matrix Cntrllr J606·3
Jl17-4 Gray, +SV to Dot Matrix Cntrllr J606·S
Jl18-'
Key
J118-2 Gray-Yellow, +12V to playfield board
Jl18-3 Black, ground to playfield board
J118-4
N/C
J119-1 White-Violet, 6.8Vac, G.I. to Coin Door Srd J2-3
J119-2 Key
J119-3 Violet, return, G.I. to Coin Door Board J2-5
J120-1
N/C
J120-2 Orange, return, G.I. to insert panel
J120-3
N/C
J120-4 Key
J120-5 Green, return, G.I. to insert panel
J120-6 Violet, return, G.I. to insert panel
J120-7
N/C
J120-8 White-Orange, 6.8Vac, G.I. to insert panel
J120-9
N/C
J120-10 White-Green, 6.8Vac, G.I. to insert panel
J120-11 White-Violet, 6.8Vac, G.I. to insert panel
tl
J121-1 Brown, return, G.I. to playfield
J121-2 Orange, return, G.I. to playfield
J121-3 Yellow, return, G.!. to playfield
J121-4 Key
J121-S
N/C
J121-6
N/C
J121-7 White·Brown, 6.8Vac, G.!. to playfield
J121-8 White-Orange, 6.8Vac, G.I. to playfield
J121-9 White-Yellow, 6.8Vac, G.!. to playfield
J121-10
N/C
J 121-11
N/C
J122-1 Blue-Brown, solenoid 25 drive to playfield flshr
J122·2
N/C
J122·3
N/C
J 122·4 Blue-Yellow, solenoid 28 drive to playfield flshr
J122·5
N/C
J122·6
N/C
J122·7 Key
J122·8
N/C
J122-9
N/C
J123·1 Not Used
J124·1
N/C
J 124·2 Blue-Red, solenoid 26 drive to insert flasher
J124-3 Blue-Orange, solenoid 27 drive to insert flasher
J124·4 Key
J124-5
N/C
J125·1
N/C
J125-2
N/C
J12S-3
N/C
J125·4 Key
J125-5 Black Yellow, solenoid 20 drive to insert flasher
J125·6 Blue-Green, solenoid 21 drive to insert flasher
J12S· 7 Blue-Black, solenoid 22 drive to insert flasher
J12S-8 Blue-Violet, solenoid 23 drive to insert flasher
J125-9
N/C
J 126·1 Black-Brown, solenoid 17 drive to plfd flasher
J126·2 Black-Red, solenoid 18 drive to playfield flasher
J 126·3 Black-Orange, solenoid 19 drive to plfd flasher
J126-4 Black·Yellow, solenoid 20 drive to plfd flasher
J126·5 Blue-Green, solenoid 21 drive to plfd flasher
J126-6
N/C
J126-7 Blue-Violet, solenoid 23 drive to plfd flasher
J126·B Blue-Gray, solenoid 24 drive to playfield flasher
J126-9 Key
J126·10
N/C
J126-11
N/C
J126·12
N/C
J126·13
N/C
J127-1
N/C
J127-2 Key
J127-3 Brown-Red, solenoid 10 drive to coil
J 127·4 Brown-Orange, solenoid 11 drive to coil
J127·5 Brown-Yellow, solenoid 12 drive to coil
J127·6 Brown-Green, solenoid 13 drive to coil
J127·7 Brown-Blue, solenoid 14 drive to call
J127·8 Brown-Violet, solenoid 15 drive to coil
J 127 -9 Brown-Gray, solenoid 16 drive to coil
J128-Not Used
J129·Not Used
3-29
