T.4 Solenoid Test
The Solenoid test has three modes - Repeat, Stop, and Run. Only one solenoid should pulse at
a time. The system has detected a problem if more then one solenoid pulses, a solenoid comes
on and stays on, or no solenoids pulse during the Repeat or Run modes.
Repeat:
The Repeat mode pulses a single solenoid. After entering this test, solenoid
one shows in the display and the corresponding solenoid activates.
Press the Up or
Down button to cycte through the solenoids, one at a time. The same solenoid pulses
until the Up or Down button is pressed. Either press the Escape button to return to the
Test menu, or press the Enter button to move to the next mode.
Stop: The Stop mode halts the Solenoid test. Press Enter during the Repeat mode and
the Solenoid test stops. No solenoids should be activated while the test is stopped.
Either press the Escape button to return to the Test menu, or the Enter button to move to
the next mode.
Run: The Run mode cycles through the solenoids automatically. The display shows the
name and number of the solenoid currently being pulsed.
T.S
FlasherTest
This tests the flashlamp part of the solenoid circuit exclusively. This, like the Solenoid test, has
three modes - Repeat, Stop, and Run. During this test only one flash lamp circuit should pulse at
a time. The system has detected a problem if more then one circuit pulses, a circuit stays on, or
no circuits pulse during the Repeat or Run modes.
Repeat: The Repeat mode pulses a single flash lamp. After entering this test the name
and number of the first flash lamp circuit shows in the display and the corresponding
bulb{s) flash. Press the Up or Down buttons to cycle through all of the flashlamps circuits
one at a time. The same circuit pulses until press the Up or Down button is pressed.
Either press the Escape button to return to the Test menu, or press the Enter button to
advance to the next mode.
Stop:
The Stop mode halts the Flasher test. No flash lamp circuit should be active
during this mode. Either press the Escape button to return to the Test menu, or press
the Enter button to advance to the next mode.
Run: The Run mode cycles through the flashlamps automatically.
The display shows
the name and number of the flash lamp circuit currently being pulsed as the
corresponding bulb{s) flashes.
T.6 General Illumination Test
This test checks all of the General Illumination circuits. There are two modes of operation - Stop
and Run.
Stop:
Press the Up or Down buttons to cycle through the General Illumination test
manually. All illumination is tested first, followed by an individual circuit test. The circuit
name and number shows in the display while the corresponding lamps lights. If any other
results occur the system has detected an error.
Run: Press the Enter button any time during Stop mode and the General Illumination
test cycles through automatically.
For each circuit shown in the display the
corresponding bulbs should light. If any other results occurs the system has detected a
problem.
1-17
