A-16226
Rotor Lock Door Unit Assembly
Item
part
Number
1.
AE-26-1500
2.
10-135
3.
20-8712-43
4.
01-10008
5.
B-7572-1
6.
4006-01003-04
7.
02-4738
8.
03-7066-3
9.
20-8716-1
10.
03-8844
Description
Coii Assembly
Spring
"E" Ring, 7/16 Shaft
Coii Stop Bracket
Bracket
&
Stop Assembly
Mach. Screw, #6-32 x 1/4 P-PH-S
Plunger
Coil Tubing, 1-7/8" Long
Roll Pin, 3/32 x 1/2"
Rotor Lock Door
A-16656
Up/Down Post Unit Assembly
Item
part
Number
1.
01-11471
2.
A-16655
3.
01-11470
4.
10-128
5.
A-10821
6.
A-15943
7.
4010-01008-06
8.
4008-01003-04
9.
20-8712-43
INDIANA JONES 2-34
Description
Mtg. Bracket - Up/Down Post
Plunger
&
Rod Assembly
Plunger Guide Bracket
Spring
Flipper Stop Bracket Assy.
Coil Assembly
Mach. Screw, #10-32 x 3/8 P-PH
Mach. Screw, #8-32 x 1/4 P-PH-S
"E"-Ring, 7/16" Shaft
