A-17073 Ball Eject Assembly - Special
• Associated Parts:
Item Part Number
Description
1.
A-6949-R
Spring Plate Assembly
2.
A-8268
Mounting Bracket Assembly
3.
A-7471-R
Eject Cam Assembly
4.
02-2364
Plunger Coil
5.
10-320
Spring - Eject
6.
12-6227
Hair Pin Clip (2)
7.
4700-00030-00 Flatwasher,
17/64 x1/2
x 15ga.
8.
4700-00103-00 Flatwasher,
17/64
x 1
12
x 28ga.
9.
03-8085
Armature Link
10.
20-8716-5
Roll Pin,
1/8
x
7/16"
Item Part Number
11 B-9362-L-2
a) B-7572-1
b) 01-8-508-S
c) 4006-01017-06
d) 4406-01119-00
e) AE-26-1200
f)
03-7066
12.
10-128
13.
03-7351-1-9
INDIANA JONES 2-19
11a
Description
Coil & Bracket Assembly
Bracket & Stop Assembly
Coil Retaining Bracket
Mach. Screw, 6-32 x
3/8
Nut, 6-32 ESN
Coil Assembly
Coil Tubing
Spring
Eject Sh ield
