Backbox Assembly
~- - - - - - - ~ - --
- - ---- - - - - - - -
---- - - --
- - - - - - --- . ~ - ~
--- - _ . _ - _
..
- - - - .
Item Part Number
Description
Item Part Number
Description
1.
01-6645
Venting Screen
16.
A-16100
8-Driver PCB Assembly
2.
B-10686-1
Knocker & Bracket Assy.
3.
A-12497
Upper Insert Bd Hinge Assy.
• Ribbon Cables:
4.
A-14092-5
Mounting Plate Assembly
5
A-12498
Lower Insert Bd Hinge Assy.
17.
5795-12653-03
Ribbon Cable, 3"
6.
A-12697-3
Power Driver Assembly
18.
5795-13018-01
Ribbon Cable, 9.5"
7.
A-16917-50017
WPC Sound Board
19.
5795-10938-14
Ribbon Cable, 14"
8.
A-12742-50017
WPC CPU Board
20.
5795-12838-30
Ribbon Cable, 30"
9.
A-16123-50017
Backbox Assembly
21.
5795-10938-32
Ribbon Cable, 32"
10.
01-9047
Insert Stop Bracket
11.
A-16576
Speaker / Display Assy.
• Miscellaneous Parts:
a)
5555-12924-00
Speaker, 4n, 15w
b)
5555-12856-00
Speaker, 5-1/4", 4n, 25w
A-8552-50017
Tempered Backglass Assy.
c)
5045-12914-00
Cap., 10f.lfd., 50v, (±20%)
08-7456
Backbox Glass: 27" x 18-7/8"
d)
5901-12784-00
Dot Matrix Display/Driver Bd.
31-1357-50017 Screened Translight
12.
A-14039
Dot Matrix Contoller Board
03-8228-2
Glass Channel Top (1)
13.
A-13379
Lock & Plate Assembly
03-8228-3
Glass Channel Edge (2)
a)
20-9637
Lock & Cam Kit
03-8229-1
Glass Lift Channel (1)
14.
50017-IN
Insert Board
15.
A-15472-1
Fliptronic II Board
INDIANA JONES 2-2
