IDOL ASSEMBLY REMOVAL INSTRUCTIONS
1.
Open the coin door, slide the latch handle toward the left and lift the front molding off the game.
Carefully slide the playfield glass down and off of the game. Install the Service Switch Actuator.
2.
Enter the Idol Lock Test. Move the Idol Assembly until the set screw, located on the shaft under the
plastic idol, is facing the plastic orange door. Turn off power to the game.
3.
Hold the plastic orange door down and loosen the set screw.
4.
Lift the idol assembly off of the game.
5.
Raise the playfield. Unscrew the three plain hex head sems screws. Unplug the connector to the
left of the motor.
6.
Pull the idol motor off of the playfield.
INDIANA JONES 1-48
