MINI-PLAYFIELD REMOVAL INSTRUCTIONS
1.
Turn off power to the game. Open the coin door slide the latch handle toward the left and lift the
front molding off the game. Carefully, slide the playfield glass down and off of the game. Lift the
playfield and rest it on it's support legs on the front of the cabinet.
2.
Disconnect the mini-playfield cables from the underside of the playfield. Be sure to match up the
wire colors when reconnecting the cables.
3.
Several devices must be removed before the mini-playfield is accessible. Start by removing the
bridge above the mini-playfield. There are three screws (#8), two on the top and one on the bottom.
4.
Now remove the lower left ramp. There is one nut (#8 ESN) holding the ramp to a plastic piece.
Unscrew the nut and slide the ramp out of the plate.
5.
Remove the plate and the slide. There are two screws (#8) holding the plate and two screws (#6)
holding the slide. Remove the screws and lift these devices off of the game.
6.
Loosen the set screw from the motor shaft at the rear of the mini-playfield.
7.
Next, remove the two screws (#8) holding the mini-playfield front bracket. DO NOT LET THE MINI-
PLAYFIELD DROP. IF THIS HAPPENS, THE REAR BRACKET CAN BE DAMAGED. Slide the mini-
playfield straight forward, off of the game.
BRIDGE
REAR BRACKET
located under
mini-playfield
FRONT BRACKET
located under
slide
PLATE
INDIANA JONES 1-47
