Fuse List
Audio Board
Fliptronic II
Controller
Board
II F50111
IIF50211
Dot Matrix Controller
Board
II F60211
II F60111
II F1 071111 F1 0911
" F1 061 ~
I
F11 011
II F11111
II F11211
\ I
F11311
II
F11411
Power Driver Board
Audio Board
F501 -25V Circuit, 3A, S.B.
F502 +25V Circuit, 3A, S.B.
Dot Matrix Controller Board
F601 +62V Circuit, 3/SA, S.B.
F602 -113V and -125V Circuits, 3/SA, S.B.
Power Driver Board
F101 Left Flipper, 3A, S.B. Not Used
F102 Right Flipper, 3A, S.B. Not Used
F103 Solenoid #2S-#2S, 3A, S.B.
F104 Solenoid #9-#16, 3A, S.B.
F10S Solenoid #1-#8, 3A, S.B.
F106 G.!. #5 Wht-Vio, 5A, S.B.
F107 G.I. #4 Wht-Grn, SA, S.B.
F10S G.I. #3 Wht-Yel, 5A, S.B.
F109 G.I. #2 Wht-Org, 5A, S.B.
F110 G.I. #1 Wht-Brn, 5A, S.B.
F111 Flasher Secondary, SA, S.B.
F112 Solenoid Secondary, 7A, S.B.
F113 +5V Logic, 5A, S.B.
F114 +18V Lamp Matrix, SA, N.B.
F115 +12V Switch Matrix, 3/4A, S.B.
F116 +12V Secondary, 3A, S.B.
Fliptronlc II Controller Board
F901 Upper Right Flipper, 3A, S.B.
F902 Upper Left Flipper, 3A, S.B.
F903 Lower Right Flipper, 3A, S.B.
F904 Lower Left Flipper, 3A, S.B.
Line Filter
Domestic Game SA, N.B.
Foreign Game 5A, S.B.
INDIANA JONES 1-45
