Page 60 - Indiana Jones

Basic HTML Version

LED List
019 020 021
000
CPU Board
CPU Board
019 , Blanking
020, Diagnostic
021, +5vdc
At game Turn-On
=
019 & 021 On, 020 Off
During Normal Operation
=
019 Off, 020 Flashing, 021 On
o
010
Dot Matrix Controller
Board
IIF60211
IIF60111
Dot Matrix Controller Board
010, +5V Circuit, Normailly On
LE07 ~
o
§d
LE03
00
LE02
LED 6
LE04
0
o
LED 1
II F11511
o
Power Driver Board
II F107111 F10911
II
F1
06111
F11
011
LEOS
o
Power Driver Board
LED 1, +12vdc Switch Circuit, Normally On
LED 2, High/Low Line Voltage Sensor, Normally On
LED 3, High/Low Line Voltage Sensor, Normally Off
LED 4, +5vdc, Digital Circuit, Normally On
LED 5, +20vdc, Flashlamp Circuit, Normally On
LED 6, +18vdc, Lamps Circuit, Normally On
LED 7, + 12vdc, Power Circuit (motors relays etc.), Normally On
