! IMPORTANT !
Playfield pitch angle can affect the operation of the plumb bob tilt. The plumb bob weight is among the
parts in the cash box; the operator should install the weight and adjust this tilt mechanism for proper
operation, after completion of the desired playfield pitch angle setting. The unit is factory installed for a 6-
1/2
degree angle. If an adjustment is necessary, loosen the screw at the bottom of the unit. Move the
pointer, one grove at a time to the left or the right, depending on the degree desired. Hold the pointer in
place and tighten screw.
10. Move the game into the desired location; recheck the level and pitch angle of the playfield.
11. Be sure the
required number
of ball are installed.
INDIANA JONES
uses seven balls: Six active
balls and one captive ball.
12. Pull the foam out from the Captive Ball feature in the upper right corner of the playfield.
13. Install playfield mylars if desired.
NOTE:
The
INDIANA JONES
playfield is coated with a special
hardcoat surface and does not require a protective mylar. However, mylars can be purchased through
your local Williams Distributor. Specify part number 03-8929-1 for full playfield mylar.
14. Clean and reinstall the playfield cover glass. Prepare the game for player operation.
15. To attach the line cord, remove the envelope stapled to the inside of the cabinet (near the cashbox).
Remove the four Phillips-head screws that mount to line cord cover plate to the rear cabinet. Match the
prongs on the plug with the holes in the receptacle, and push the line cord securely into place. Make sure
the cord is aligned with the indentation on the cover plate (indentation should point toward bottom of the
cabinet). Remount line cord cover plate. If desired, four tamper resistant screws have been provided in an
enevlope marked "Security Screws" (located in the cashbox) to remount cover plate.
(Part of cabinet shown
for reference only)
Receptacle
INDIANA IONES 1-4
