4. Reach into the cabinet and backbox and ensure that the interconnecting cables are not kinked or
pinched. Be careful to avoid damaging wires at any stage of the assembly process.
5. Raise the hinged backbox upright and latch it into position.
Unlock the backbox, and remove the
backglass.
Remove the shipping block holding the Insert Board. Unlatch and open the Insert Board.
Carefully lift up the Speaker Panel and lay it down on the playfield glass. (Be careful not to damage the Dot
Matrix Display/Driver.)
This allows access to the bolt holes used for securing the backbox upright. To
secure the backbox, install the washer-head mounting bolts through the bottom holes of the backbox into
the threaded fasteners in the cabinet.
Close and latch the Insert Board. Replace the Speaker Panel.
Reinstall the backglass, and lock the backbox.
'&CAUTION
FAILURE
TO
INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER
TRANSPORT
a pinball game with the hinged back box erect. Always lower the backbox forward onto
the playfield cabinet on a layer of protective material to prevent marring or damage and possible personal
injury.
6. Extend each leg leveler
slightly
below the leg bottom, so that all four foot pads are extended about the
same distance. Remove the cabinet from its support and place it on the floor.
7. Unlock and open the coin door. Move the molding latch lever toward the left side of the game. Lift the
front molding off the playfield cover glass return the latch lever toward the right, and close the coin
door.Carefully slide the glass downward, until
it
clears the grooves of the left and right side moldings. Lift
the glass up and away from the game. Raise the playfield. (See page 1-5.)
8. Install the gun handle. Remove the gun handle from the inside bottom of the cabinet. Then, using the
hardware included with the gun handle plus two more 10-24 bolts, 10-24 ESN nuts and .219x.SOOx.063
flat washers located in the parts bag, attach the gun handle to the outside of the cabinet in the upper right
corner. (See diagram below.) After the gun handle is in place, plug the connector from the handle into the
matching connector from the cabinet.
9. Place a level or an inclinometer on the playfield surface. Adjust the leg levelers for proper playfield level
(side-to-side).
NOTE:
It is recommended that this measurement be made
ON
the playfield, not the
cabinet nor the playfield cover glass. Tighten the nut on each leg leveler shaft to maintain this setting.
INDIANA JONES 1-3
