Power Driver Board Continued ...
J12S-1 Black-Brown, sol 17 drive, to playfield fiashlamps
J12S-2 Black-Red, sol. 18 drive, to playfield flashlamps
J12S-3 Black-Orange, sol. 19 drive, to playfield flashlamps
J12S-4 Black-Yellow, sol. 20 drive, to playfield flash lamps
J12S-5 Blue-Green, sol. 21 drive, to playfield flashlamps
J12S-S Blue-Black, sol. 22 drive, to Bridge Driver assy
J
1-1
J12S-7 Blue-Violet, sol. 23 drive, to Bridge Driver assy Jl-2
J12S-S Blue-Gray, sol. 24 drive, to playfield flashlamps
J12S-9
N/C
J12S-10
NfC
J12S-11
NfC
J12S-12
NfC
J12S-13
NfC
J127-1 Brown-Black, sol. 9 drive, to playfield coil
J127-2
NfC
J127-3 Brown-Red, sol. 10 drive, to playfield coil
J127-4 Brown-Orange, sol. 11 drive, to playfield coil
J127-5 Brown-Yellow, sol. 12 drive, to playfield coil
J127-S Brown-Green, sol. 13 drive, to playfield coil
J127-7 Brown-Blue, sol. 14 drive, to playlield coil
J127-8 Brown-Violet, sol. 15 drive, to playfield coil
J127-9 Brown-Gray, 501.16 drive, to playlield coil
J12B-1
NfC
J128-2
N/C
J12B-3
NfC
J12S-4
NfC
J128-5
NfC
J129-1
N/C
J129-2
NfC
J129-3
N/C
J129-4
NfC
J129-5
NfC
J130-1 Violet-Brown, sol. 1 drive, to playfield coil
J130-2 Violet-Red, sol. 2 drive, to playlield coil
J130-3
NfC
J130-4 Violet-Orange, sol. 3 drive, to playlield coil
J130-5 Violet-Yellow, sol.4 drive, to playlield coil
J130-6 Violet-Green, sol. 5 drive, to playlield coil
J130-7 Violet-Blue, sol. 6 drive, to playlield coil
J130-8 Violet-Black, 501.7 drive, to playlield coil
J130-9 Violet-Gray, sol. 8 drive, to playlield coil
J131-1
NfC
J131-2
NfC
J131-3
NfC
J131-4
NfC
J131-5
NfC
J132-1
NfC
J132-2
N/C
J132-3
NfC
J132-4
NfC
J132-5
NfC
J133-1 Red-Brown, lamp row 1, to playlield lamps
J133-2 Red-Black, lamp row 2, to playfield lamps
J133-3
NfC
J133-4 Red-Orange, lamp row 3, to playfield lamps
J133-5 Red-Yellow, lamp row 4, to playfield lamps
J133-S Red-Green, lamp row 5, to playlield lamps
J133-7 Red-Blue, lamp row 6, to playfield lamps
J133-8 Red-Violet, lamp row 7, to playfield lamps
J133-9 Red-Gray, lamp row 8, to playfield lamps
J134-1
N/C
J134-2
N/C
J134-3
N/C
J134-4
NfC
J134-5
NfC
J134-S
N/C
J134-7
N/C
J134-S
NfC
J134-9 Red-Gray, lamp row 8, to coin door
J135-1
N/C
J135-2 Red-Black, lamp row 2, to speaker panel J 1-1
J135-3
N/C
J135-4
NfC
J135-5
N/C
J135-S
N/C
J135-7 Red-Blue, lamp row 6, to speaker panel, Jl-6
J135-6
NfC
J135-9 Red-Gray, lamp row 8, to speaker panel, Jl-5
J136-1
NfC
J13S-2
N/C
J136-3 Yellow-Gray, lamp column 8, to coin door
J137-1 Yellow-Brown, lamp column 1, to playfield lamps
J137-2 Yellow-Red, lamp column 2, to playfield lamps
J137-3 Yellow-Orange,
lamp column 3, to playfield lamps
J137-4 Yellow-Black, lamp column 4, to playfield lamps
J137-5 Yellow-Green, lamp column 5, to playfield lamps
J137-S Yellow-Blue, lamp column 6, to playlield lamps
J137-7 Yellow-Violet, lamp column 7, to playfield lamps
J137-B
NfC
J137-9 Yellow-Gray, lamp column 8, to playfield lamps
J136-1 Yellow-Red, lamp column 2, to speaker panel Jl-3
J138-2
NfC
J136-3
N/C
J138-4 Yellow-Black, lamp column 4, to speaker panel Jl-5
J138-5
N/C
J136-S
N/C
J13S-7
N/C
J138-6 N/C
J138-9
NfC
INDIANA JONES 3-34
