Power Driver Board Continued ...
Jll0-l
N/C
Jll0-2
N/C
Jll0-3
N/C
Jll0-4
N/C
Jll0-S
N/C
Jll0-6
N/C
Jll0-7
N/C
Jl10-S
N/C
Jll0-9
N/C
Jll1-1
N/C
Jl11-2
N/C
J111-3
N/C
J111-4
N/C
Jl11-S N/C
Jl12·1 White-Green, 9.8VAC, from xformer secondary
Jl12-2 White-Green, 9.8VAC, loop from Jl12-1
J112-3 White-Green, 9.8VAC, from xformer secondary
J112-4 N/C
Jl12-S White-Green, 9.8VAC, loop from Jl12-3
Jl13, 34-pln Ribbon Cable, data,
To/from
CPU J211
Jl14-1 Gray-Green, +12V, to J210-6,7; J904-2
J114-2 Gray-Green, +12V, to 8-Driver Brd. J2-6
J114-3 Gray, +5V, to 8-Driver Brd. J2-3
J114-4 Gray, +5V, to J21 0-4,5; J3-1 ,3; J904-1
J114-S Black-White, ground, to J210-1 ,3; J3-4,5; J904-4,5
J114-6 N/C
J114-7 Black-White, ground, to 8-Driver Brd. J2-1
Jl1S-1 Yellow-White, 6.8VAC, from xformer secondary
JllS-2 White-Brown, 6.8VAC, from xformer secondary
JllS-3 White-Brown, 6.8VAC, from xformer secondary
JllS-4 White-Orange, 6.8VAC, from xformer secondary
JllS-S White-Yellow, 6.8VAC, from xformer secondary
JllS-6 White-Yellow, 6.8VAC, from xformer secondary
JllS-7 Orange, 6.8VAC, from xformer secondary
JllS-S Orange, 6.8VAC, from xformer secondary
Jl1S-9
N/C
Jl1S-10 Green, 6.8VAC, from xformer secondary
Jl1S-11 Brown, 6.8VAC, from xformer secondary
Jl1S-12 Brown, 6.8VAC, from xformer secondary
J116-1
N/C
J116-2 Gray-Yellow, +12V, to Coin Door J2-4
J116-3 Black, ground, to Coin Door J2-5
Jl16-4
N/C
Jl17-1
N/C
Jl17-2 Gray-Yellow, +12V, to Dot Matrix ControllerJ606-7
Jl17-3 Black, ground, to Dot Matrix Controller J606-3
Jl17-4 Gray, +5V, to Dot Matrix Controller J606-5
Jl19-1 White-Violet, 6.8VAC, G.I. to Coin Door Brd J2-2
Jl19-2
N/C
J119-3 Violet, return, G.I. to Coin Door Brd J2-1
JllS-l
N/C
Jl1S-2 Gray-Yellow, + 12V, to Playfield Boards and airplane flashers
Jl1S-3 Black, ground, to Playfield Boards and airplane flashers
JllS-4
N/C
J120-1
N/C
J120-2
N/C
J120-3 Yellow, return, G.I. to backbox
J120-4
N/C
J120-S Green, return, GJ. to backbox
J120-6
N/C
J120-7
N/C
J120-S
N/C
J120-9 White-Yellow, 6.8VAC, G.I. to backbox
J120-10 White-Green, 6.8VAC, G.I. to backbox
J120-11
N/C
J121-1 Brown, return, G.I. to playfield
J121-2 Orange, return, G.I. to playfield
J121-3
N/C
J121-4
N/C
J121-S
N/C
J121-6 Violet, return, G.I. to playfield
J121-7 White-Brown, 6.8VAC, G.I. to playfield
J121-S White-Orange, 6.8VAC, G.I. to playfield
J121-9
N/C
J121-10
N/C
J121-11 White-Violet, 6.8VAC, G.I. to playfield
J122-1 Blue-Brown, sol. 25 drive, to playfield flashlamp
J122-2 Blue-Red, sol. 26 drive, to playfield flashlamp
J122-3 Blue-Orange, sol. 27 drive, to playfield flashlamp
J122-4 Blue-Yellow, sol. 28 drive, to playfield coil
J122-5
N/C
J122-6
N/C
J122-7
N/C
J122-S
N/C
J122-9 Violet-Green, sol. tieback diode, to playfield coil
J123-1
N/C
J123-2
N/C
J123-3
N/C
J123-4
N/C
J123-S
N/C
J124-1
N/C
J124-2 Blue-Red, sol. 26 drive, to backbox flash lamp
J124-3 Blue-Orange, sol. 27 drive, to backbox flashlamp
J124-4
N/C
J124-S
N/C
J12S-1 Black-Brown, sol. 17 drive, to backbox flashlamp
J12S-2
N/C
J12S-3
N/C
J12S-4
N/C
J12S-5 Black-Yellow, sol. 20 drive, to backbox flashlamp
J125-6 Blue- Green, 501.21 drive, to backbox flashlamp
J12S-7
N/C
J12S-S
N/C
J125.9
N/C
INDIANA JONES 3-33
