A-17168 Mini-Playfield Assembly
Item Part Number
Description
1.
36-50017-2
Mini-Playfield Hard Coat
2.
H-16868
Cable, Mini-Playfiled
3.
A-16746
s-Larnp
& G.!. PCB
4.
A-16747
6-Lamp & G.!. PCB
5.
03-8318-9
Light Hood Obi Side Stripple (Red)
6.
03-8319-16
Star Post (Trans. Yellow)
7.
23-6300
Rubber Ring,
5/16"
8.
03-8938
Ball Guide - Left
9.
03-8937
Ball Guide - Right
10.
A-16734
Drive Bracket Assembly
11.
20-8712-25
"E" Ring,
1/4"
Shaft
12.
A-16736
Front Pivot Mounting Assembly
13.
A-16735
Pivot Bracket/Shaft Assembly
14.
4408-01118-00
T-Nut, 8-32
15.
03-7655
Cable Clamp.
1/2"
16.
A-12688
Rollover Switch Assembly
17.
A-12688-1
Ro"over Switch Assembly
18.
01-11654
Opto Guard Bracket
19.
A-16908
LED Assembly-RTV
20.
A-16909
Photo Transistor Assembly-RTV
21.
4108-01001-26
Sh. Metal Screw, 8 x
1-5/8"
P-PW
22.
4700-00072-00
Flatwasher, 17/64 x 1/2 x 21ga.
23.
4108-01170-16
PLS No. 8x 1" HWH, Trilobular
24.
12-6466-2
Wire Ball Guide, 1/2"
25.
03-7655-4
Cable Clamp, 1/4·
26.
4106-01114-08
Sh. Metal Screw,
#6x1/2"
PLHWH-A
27.
4106-01115-16
Sh. Metal Screw, #6 x 1" PLHWH-A
28.
4104-01
OOH
0
Sh. Metal Screw, #4 x
5/8"
PPH
29.
17-1116-4
Wire, 22AWG (Yellow)
30.
4008-01017-10
Mach. Screw, 8-32 x 5/8 PRH-S
INDIANA JONES 2-36
