Game Operation
&
CAUTION
Mter assembly and installation at its site location, this game must be plugged into a properly
grounded outlet to prevent shock hazard, and to assure proper game operation. DONOT use a
'cheater' plug to defeat the gro1Dldpin
011
the line cord.
DO
NOTcut off the ground pin.
Powering Up. With the coin door closed. plug the game in, and switch it On. using the On-Orr
switch. In normal operation. Testing shows in the displays as the game performs Start-up
Tests. Once the Start-up Tests have been successfully completed the last score is displayed.
After that. the game goes into the Attract Mode (playfield and backbox lamps flashing. sounds
being heard. etc., if the operator does not change the Factory Setting).
Note: After the game has been on location for a period of time. the Start-up Tests may contain
messages concerning game problems.
The section entitled 'Problem Analysis Messages'
contains more details concerning messages displayed at each game tum-on.
Open the coin door and press the Begin Test switch. The display shows the game name, the
game number. and the game software revtsion. The message changes. The display shows the
sound
software revision, the revision level of the system software. and the date the game
software was revised.
Example:
Hurricane
150012
Rev.L-X
Sound Rev.
L-1
SY.O.xo
X-X.g1
Press the Enter button to enter the WPC Menu System (refer to the section entitled "Menu
System Operation" for more information). Perform the entire Test Menu routine to verify that
the game is operating satisfactorily.
Successful completion of the tests in the Test Menu
routine shows that the game is ready to begin earning your investment return.
Attract Mode·. After completing the Test Menu routine. press the Escape button three times to
enter the Attract Mode. During the Attract Mode, playfleld and backbox lamps blink.
The
player score displays exhibit a series of messages informing the player concerning:
A
Recent highest scores":
B. A "custom message"
C. The score to achieve to obtain a Replay
awards:
These (or similar) displays reappear occasionally. accompanied by sounds and music. until a
player initiates game play by inserting a coin, or when credits are available. pressing the Start
button.
Credit Posting.
Insert coin(s). A sound is heard for each coin, and the player score display
shows the number of credits purchased. So long as the number of maximum allowable credits"
are
Naf
exceeded by coin purchase or high score, credits are posted correctly.
Starting a Game. Press the Start button once. A startup sound plays. and the Credit amount
shown in the display decreases by one. The display flashes 00 (until the first playfield switch is
actuated). and shows ball 1. Additional players may enter the game by pressing the Start
button once for each player. before the end of play on the first ball.
• - operator-adjustable feature
Hurricane 1-5
