T.7 Sound and Music Test
The Sound and Music Test checks the audio circuits. This test has three modes for testing the sound and
music circuits, Run, Repeat and Stop.
Run •
The Run mode steps through a sequence of sounds and music. Pressing the
Up
or
Down button during this portion of the Sound and Music test advances to a particular sound or tune
without having to wait for the program to play all the sounds available in the test. A sound or tune should
be heard for each name and number that appears in the display. Any other results indicates the system
has detected a problem.
Repeat·
Press the Enter button at any time during the Run mode to cause the program to stop and
repeat a particular sound or tune. The same sound should repeat continuously until the
Up
or Down
button is pressed. Any other resuHs indicates the system has detected a problem.
Stop •
Press the Enter button at any time during the Repeat mode to stop this test altogether.
Nothing should be heard. Any other results indicates the system has detected a problem.
T.B Single Lamp Test
The number assigned
to
each lamp indicates the lamp's position in the matrix. The number on the left
indicates the column. The number on the right indicates the row. Example - lamp 23 means 2nd column,
3rd
row.
This test checks each lamp circuit individually. Press the Up or Down button to cycle through this test. For
each name and number that is shown in the display the corresponding lamp should light. Any other
results indicates the system has detected a problem.
T.9 All Lamps Test
ThiS test causes all the controlled lamps to flash at the same time. Every controlled lamp should flash. Any
other results indicates the system has detected a problem.
T. 10 Lamp and Flasher Test
This test causes aUthe flashlamps and the controlled lamps to flash at the same time. The controlled lamps
blink, while the flashlamps cycle from highest to lowest. Any other results indicates the system has
detected a problem.
T.11 Display Test
This test automatically checks every dot in the Dot Matrix Display.
A series of patterns appear in
sequence.
Each pattern turns On and Off a section of dots. Every dot on the matrix display should be
turned On and off during this test.
FISH TALES 1·14
