FISH TALES 1~13
T.4 Solenoid Test
The Solenoid Test has three modes, Repeat. Stop, and Run. Only one solenoid should pulse at a time.
The system has detected a problem if; more then one solenoid pulses, a solenoid comes On and stays
On or, during the Repeat and Run mode, no solenoid pulses.
Repeat
~ The Repeat mode pulses a single solenoid. After entering this test, Solenoid 1 shows in
the display and the corresponding solenoid activates. Press the Up or Down button to cycle through the
solenoids, one at a time. The same solenoid pulses until the Up or Down button Is pressed. Either press
the Escape button to return to the Test Menu, or press the Enter button
10
move to the next mode.
Stop -
The Stop mode halts the Solenoid Test. Press Enter during the Repeat mode and the
Solenoid Test stops. No solenoids should be activated while the test is stopped.
Either press the
Escape button to return to the Test Menu, or the Enter button to move to the next mode.
Run ~
The Run mode cycles through the solenoids automatically. The display shows the name
and number of the solenoid currently being pulsed. Either press the Escape button to return to the Test
Menu.
T.5 Flasher Test
ThiS tests the flash lamp part of the solenoid circuit exclusively.
This, like the Solenoid Test, has three
modes, Repeat, Stop. and Run. During this test, only one flashlamp circuit should pulse at a time. The
system has detected a problem if more then one circuit pulses, a circuit stays On or, during the Repeat
and Run mode, no drcuit pulses.
Repeat
~ The Repeat mode allows you to pulse a single flashlamp. Once you have entered this
test, the name and number of the first flashlamp Circuit shows in the display and the corresponding bulb(s)
flashes. Press the Up or Down button to cycle through all of the flash lamps Circuits one at a time. The
same circuit pulses until you press the Up or Down button. Either press the Escape button to return to the
Test Menu, or press the Enter button to advance to the next mode.
Stop -
The Stop mode halts the Flasher Test. No flash lamp circuit should be turned On during
this mode. Either press the Escape button to return to the Test Menu, or press the Enter button to
advance to the next mode.
Run ~
The Run mode cycles through the flash lamps automatically. The display shows the name
and number of the circuit currently being pulsed. and the corresponding bulb(s) flashes. Either press the
Escape button to return to the Test Menu.
T.6
General Illumination
This test checks all of the General Illumination circuits. There are two modes of operation, Stop and Run.
Stop ~
Press the Up or Down buttons to cycle through the General Illumination Test manually. All
illumination is tested first, followed by an individual circuit test. The
ctrcult
name and number shows in the
display while the corresponding lamps lights. If any other results occur the system has detected an error.
Run ~
Press the Enter button any time during Stop mode and the General lllumination. Test
cycles through automatically.
For each circuit shown in the display the corresponding bulbs should light.
If any other results occurs the system has detected a problem.
