MINI-PLAYFIELD SERVICE INSTRUCTIONS
Door Release Bracket
@
Remove Nuts
MINI-PLAYFIELD - BOTTOM VIEW
TO REMOVE THE MINI-PLAYFIELD ASSEMBLY (Bottom of Playfield):
1. Mini-playfield should be in the down position.
2. Turn power OFF.
3. Remove (2) nuts, and lift off Door Release Bracket. When reassembling, position
mini-playfield in the middle position (use diagnostics). Then, mount Release bracket
against flip-up target reset lever, so that the targets drop. Tighten nuts.
4. Disconnect all cables from mini-playfield assembly.
Mini-playfield
Side Bracket Screws
o
CoverlSide Screws
MINI-PLAYFIELD - TOP VIEW
(Top of Playfield)
5. Remove (4) screws on Cover/Side Bracket.
6. Remove (4) screws from Mini-playfield Side Brackets.
7. Carefully lift mini-playfield up, then tilt back slightly to avoid catching motor.
