PINBALL GAME ASSEMBLY INSTRUCTIONS
DOCTOR WHO IS A 3 BALL GAME.
po wee:
Domestic 120V
@
60 Hz
Foreign230V
@
50 Hz
Japan 100V
@
50Hz
Isms:
32
0
F to 100
0
F
(0
0
C to 38
0
C)
Humiditv:
Not to exceed 95% relative.
Dimensions:
Width: 26" Approx.
Depth: 56" Approx.
Height: 85" Approx.
Weight:
Approx. 286 Ibs. (crated)
1. Remove all cartons, parts, and miscellaneous items from the shipping container and set them aside.
2. Place the cabinet on a support and attach rear legs using leg bolts. Leg levelers and leg bolts are provided
among the parts in the cash box.
3. Attach the front legs (after installing leg levelers), using leg bolts. See diagram below.
Detail View·
Leg Leveler
Approx. Playfield
PItch Anile:
8 • 8 112
o.g"'''
C·l0843·1
Leg
.
-,
,
'
See 0.1811 View \
:
._.--
..
~
Pinball Assembly, Playfield Pitch Angle, and Leg Leveler Details.
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are not kinked or pinched. Be
careful to avoid damaging wires at any stage of the assembly process.
5. Raise the hinged backbox upright and latch it into position. Unlock the backbox, and remove the backglass,
storing it carefully to avoid scratches. Remove the shipping block holding the Insert Board. Unlatch and open
the Insert Board. Carefully lift the Speaker Panel and lay it down on the playfield glass. Be careful not to
damage the Dot Matrix Display/Driver Board. This allows access to the bolt holes used for securing the
backbox upright. Install the washer-head mounting bolts through the bottom holes of the backbox into the
threaded fasteners in the cabinet to secure the backbox. Close the Insert Board and latch it in position.
Replace the Speaker Panel. Reinstall the backglass, and lock the backbox.
&
CAUTION
FAILURE
TO
INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect. Always lower the backbox forward
onto the playfield cabinet on a layer of protective material to prevent marring or damage and possible personal
injury.
6. Extend each leg leveler slightly below the leg bottom, so that all four foot pads protrude approximately the same
distance. Remove the cabinet from its support and place it on the floor.
DOCTOR WHO 1-2
