Game
Wiring and
Schematics
m
o
-I
o
Z
-I
::I:
:rJ
m
m
CONNECTOR & COMPONENT IDENTIFICATION
Each plug or jack receives a number that identifies the circuit board and position on that
board that it connects to. J-designations refer to the male part of a connector.
P-designations refer to the female part of a connector. For example, J101 designates
jack 1 of board 1 (a Power Driver Board Board jack); P206 designates plug 6 of board 2
(a CPU Board plug). Identifying the specific pin number of a connector involves a
hyphen, which separates the pin number from the plug or jack designation. For
example, J101-3 refers to pin 3 of jack 1 on board 1.
Other game components may also have similar numbers to clarify their locations or
related circuits. For example, F501 refers to a fuse located on the Sound Board.
Prefix numbers for the WPC circuit boards are listed below.
1- Power Driver Board
2- CPU Board
5- Sound Board
6- Dot Matrix Controller
Dot Matrix Display/Driver Board
9 -Fliptronic II Controller Board
Schematics for standard WPC backbox boards are found in the WPC Schematics
Manual. Playfield, cabinet, and all other backbox board schematics are found in
this section.
DOCTOR WHO 3-1
