LOWER PLAYFIELD PARTS LOCATIONS
1Wn
part Number Description
1.
01-9211
Plfd. Hanger Bracket (2 Used)
2.
A-16765
Outhole Ball Trough Assembly
3.
A-15849-R-2 Flipper Assembly, Lower Right
4.
01-11781
Leg Support (2 Used)
5.
A-17811
Kicker Arm (Slingshot) Assy., Right
A-17809
Coil
&
Bracket Assembly
10-128
Spring
6.
A-17898
6-Lamp PCB Assembly
7.
A-17899
25-Lamp PCB Assembly
8.
A-17620
Chute
&
Ball Popper Assembly
9.
A-16989
Cryoclaw Assembly
10.
A-17811
Kicker Assembly
A-17809
Coil
&
Bracket Assembly
11.
A-9415-2
Jet Bumper Coil Assembly
12.
A-17749-2
P!fd. Slide Mechanism, Right
13.
A-17902
5-Lamp G.I. PCB Assembly
14.
A-17624
3-Lamp Board Assembly
15.
A-15542
Motor EMI Assembly
16.
A-17421
Ramp Diverter Assembly
17.
A-17215
Ball Popper Assembly - Rear
18.
A-16120
DC Motor Control Assembly
19.
A-17749-1
Plfd. Slide Mechanism, Left
20.
A-17823
Ball Popper Trough Assembly
21.
A-17916
5-Lamp PCB Assembly
22.
A-14876-L
Flipper Assembly, Upper Left
23.
B-9361-R
Ball Eject Assembly
A-17809
Coil
&
Bracket Assembly
24.
A-17811
Kicker Arm (Slingshot) Assy., Left
A-17809-1
Coil
&
Bracket Assembly
10-128
Spring
25.
A-15576
7-Switch Opto PCB Assembly
26.
A-15849-L -2 Flipper Assembly, Lower Left
27.
A-14525
Kicker Bracket Asserrbly
Underside of Playfield, Viewed in Raised Position
DEMOLITION MAN 2-40
