UPPER PLAYFIELD PARTS LOCATIONS
JIlIn
pad Number
Description
1
A-14525
Kicker Bracket Assembly
2
A-16765
Ball Trough Assembly
3
01-12289
Ball Guide Arch-Right
4
A-17166-1
Flipper Ball Guide
5
A-17811
Nylon Kicker
~)
A-17809
Coil & Bracket
6
12-7134
Wire Ramp #1
7
A-17291
Incline Ramp
8
A-18017-6
Standup Target
9
12-7171
Wire Cage
10
A-1762O
Chute & Ball Popper
11
A-1S019-6
Standup Target
12
01-12207
Ball Guide #5
13
01-12209
Ball Guide #7
14
A-I7785
Ramp #2
15
A-17811
Nylon Kicker
15a)
A-17809
Coil & Bracket
16
12-6466-18
Ball Guide Wireform
17
A·17784
Diverter Ramp
18
8-9414
Jet Bumper Assembly
18a)
A-9415-2
Jet Bumper Coil Assembly
1ab)
A·1203O-2
Jet Bumper Switch Assembly
19
A-17241
Ramp Divertsr
19a)
A·18242
Diverter Ball Guide
20
A·I8017-6
Standup Target
21
A·17786
Ramp #3
22
A-17215
Rear Ball Popper
23
12·7166
Single Wire Ramp
24
A·17771
Feed Ramp
25
12·7181
Drain & Wireform
26
A·17597
Elevator Assembly
27
A·16989
Cryoclaw Assembly
28
12·7182
Double Wire Ramp
29
A-1S018·4
Standup Target
30
A-17644
Opto car Tunnel Assembly
3Oa)
03-9000
Car Tunnel
31
01·12323
Ball Guide #9
32
A-17410
Car Catapult
33
20-925()"5
Flipper Shaft & Paddle
33a)
23-6519-4
Red Rubber Ring
33b)
FL·11630
Flipper Coil
34
01-12206
Ball Guide #4
35
A·18018-4
Standup Target
36
A-1S017-6
Standup Target
37
8-9361-R
Ball Eject Assembly
37a)
A-17809
Coil & Bracket
38
12·7135
Wire Ramp #2
39
01·12204
Ball Guide #2
40
01-12205
Ball Guide #3
41
12-7136
Wire Ramp #3
42
A-17811
Nylon Kicker
42a)
A-17809-1
Coil & Bracket
43
A-17166-2
Flipper Ball Guide
44
2O-925()"S
Flipper Paddle & Shaft
44a)
23·6519-4
Red Rubber Ring
44b)
FL-17629
Flipper Coil
45
01-12290
Ball Guide Arch·Left
Parts Under Bottom Arch
A-13204-50028 Bottom Arch Assembly
31-1927-50028 Screened Bottom Arch
12-7168
Wire Fence
20-9041
Tinnerman Speednut
20-9601
#8-32 Nut Retainer
00 0
00 0 0
000
OCJ
"The
DEMOLITION MAN
hardcoat playfield does not
require a full mylar.
However Mylars can be purchased
through your local Williams Distributor.
Not Shown
Part Number
Description
A-1S016-1
A·1S016-2
03-9118-1
16-50028-1
20-6500
20-9928
20-9929
20-9935
Control Handle-Right
Control Handle-Left
"Full Playfield Mylar
Instruction Card
Steel Ball
Olds 442 Car
Ultralite Police Car
Eyeball
DEMOLITION
MAN
2-39
