A-14525
Kicker 8racket Assembly
8-10686·1
Knocker Assembly
.IWn
part Number
Description
.IWn
part Number
Description
1.
A-6306-2
Bell Armature Assembly
1.
A-53S7
Coil Plunger Assembly
2.
A-14526
Mtg. Bracket Assembly
2.
01-11273
Mtg. Bracket Assembly
3.
01-S-50S-T
Solenoid Bracket
3.
AE-23-S00
Coil Sub-Assembly
4.
10-135
Solenoid Spring
4.
01-S-50S-T
Coil Retaining Bracket
5.
23-6420
Rubber Grommet
5.
23-6420
Rubber Grommet
6.
AE-23-S00
Coil Assembly
6.
4008-01017 -04 Mach. Screw,
S/32
x 1/4·P-RH
7.
03-7067-5
Coil Tubing
7.
H-11S35
Knocker Cable
S.
4008-01017-04
Mach. Screw, #S-32 x 1/4"P-RH
S.
03-7067-5
Coil Tubing
9.
03-S523
Insulator
DEMOLITION MAN 2-22
