A.S Printer Adjustments
(optional board required)
A.S
01
A.S
02
A.S
03
A.S
04
A.S 05
A.S
06
Column Width
The column width to be printed.
Range: 22 to 80.
Lines Per Page
The amount of lines per page.
Range: 20 to 80.
Pause Every Page
Choose whether the printer pauses at the end of a page.
YES
The printer does pause.
NO
The printer doesn't pause.
Printer Type
Select the type of printer: Parallel, Serial, ADP, Mini-Drucker, or NSM.
Serial Baud Rate
Select which baud rate to use for serial or ADP communications (bit rate):
300, 600, 1200,
2400, 4800,
or
9600.
Serial D.T.R. (Data Terminal Ready)
When a serial printer is used, this line may be connected to a printer output line signaling
that the printer is busy.
NORMAL -Nonnal D.T.R. signal goes low to indicate the printer is not ready.
INVERTED -Inverted D.T.R. (busy) signal goes high to indicate the printer is not ready.
IGNORE -D.T.R. signal is ignored.
DEMOLITION MAN 1·35
