Park Elevator
The Park Elevator function runs the elevator motor until the elevator index position is detected.
The motor is then shut off.
Magnet On
The Magnet On function turns on the claw magnet. The magnet is turned on solidly for a short
period and then pulsed for a longer period. The Magnet On function times out after several
seconds and shuts off the magnet to avoid overheating it.
Claw Test Error Messages
During the various claw test functions the CPU may detect an error condition. The messages are
explained below.
Elevator Error
The Claw test displays this message when the elevator motor is running and the elevator index
switch is not detected after several seconds.
Claw Out of Range
The Claw test displays this message when it detects that the claw arm is out of range (see Theory
of Operation later in this section).
To
move the claw arm when
it
is out of range select Claw Left or Claw Right, as appropriate, and
hold in either flipper button before pressing Enter. Do not move the claw arm by hand.
Claw Movement Error
The Claw test displays this message when the claw motor is running and neither position switch is
detected after several seconds.
Magnet Error
The Claw test displays this message after it has tried several times to pick up the ball from the
elevator.
T .15 Empty Balls Test
The Empty Balls test clears all balls from any lock-up device, including
the outhole trough. Press the Enter button to begin the test and the Escape button to stop it.
