Factory
Set ting s Re st ored.
This message indicates that the CMOS RAM (US) no I.onger retains any custom Pricing or Game
Adjustment settings and has reverted to faclory def'aull sellings. Generally·, the
following
CPU
checks.will isolate the cause of the CMOS RAM memory failure. The voltage at p.in 28 and pin 26
of
us
should be +5V (game turned On) and at least +4V (g'ame turned Off). When Ihe vollage'
drops below
+4V,
memory reset occurs. Check the batteries and battery holder. Be-sure that the
batteries are good and that there is no contamination on the battery .holder terminals. Turn the
game OFF. and use
an
ohmmeter to check diodes 01 and D2 On the CPU
8oard.
01 .should read
o
ohms when forward-biased and infinite ohms when reverse-biased.
02 should read 15 ohms
when forward-biased and infinite ohms when reverse-biased.
(Readings laken with an analog
meter.)This
rnessage
can also indicate that there Is an OPen diode pn' a
SOV
0011and noise ts
entering the circuit. .
TOp RIght Ramp DOWN ERROR
Top RIght Ramp UP
EHROR
The trap
door
did '
not get
to lis
intended peshlon,
Go
to "T14 Top
RIght
Ramp
Test" and Check
the RAM P QOWN switch, the ramp linkage and the coils lor proper
operatlon,
Magnet
Left Error
Magnet
Right
Error
Magnet
Power
Erwr
Magnet Load
Error
Magnet
Unload Error
.
The Magnet unit.had a
problem.
Left or right errors arernost likely swit.ch problems.
Power errors
usually
means
a
loose
wire
or
connector
to
magnet.
Load error can mean a faulty shooter
ramp,
a
ball
on the magnel opto, or no ball in the trough.
Unload error can mean faulty
"8an
On Magnet" opto (sw. #82), left gate, right gate opto.or right
gate,
•
opt e Theo.ry
The opto receiver (detector)
sneutd
be approximately 0,1 - 0.7 volts when
the
opto beam is
unblocked
and
approximately
11 - 13 volts
when
tns opto
beam
is
blocked. The
opto
transrnltter
(emitter L.E.D.) should
always be approximately 1.4 volts.
Note.:
The transmitter
(L.E.O.)
is larger
than the receiver (~
protrudes
further
from lis case),
Transmittgr
1.0- 1.4Volts
'Receiver
O.1·0.7V lJl'lblocked
11·1.3V
Blocked
lnlrared
Ray
Green
a
WHT
Gray
Black
Gray
Orange
ilratula t-40
