T.7' Sound and Music Test
The Sound and Music Test checks the audio circuits.
This test has three modes for testing the sound and music circuits, Run. Repeat and Stop.
Running
The Running mode steps through a sequence of sounds and music. PressIng the Up or
Down button during this portion of the Sound and Music test advances to
a
particular
sound or
tune
without having to wart for
the
program
to
play all
the
sounds available
m the
test.
A
sound
01'
tune should be heard for each name and number that appears in the
display. Any other results lndlcates
the
system has
detected
a problem.
Press the Enter
button at
any time during the Running mode to cause the program to
stop and repeat a particular sound/tune.
The same sound should repeat continuously
until the Up or Down button is pressed.
Any other results indicates the system has
detected a problem.
Press the Enter button at any time during
the
Repeat mode to slop this test altogether.
Nothing should be heard.
Any
other results indicates the system has detected
a
problem.
Repeat
'Stopped
6
T.8
Singl e Lamp Test
The number assigned to each lamp Indicates the lamp's position
in
the matrix. The number on the lett indicates Ihe column. The number on the right indicates the
row. Exampla- Lamp 23 means znd column, 3rd row .
This test checks each lamp circuit individually. Press'the Up or Down button to cycle through this
test. For each name and number that is shown in the dlspJay the corresponding lamp should light
Any other results Indicates Ihe
svstem
has detected a problem.
.
T.9
All Lamps Tes t
This test causes all the controrled lamps to flash at the same time.
Every controlled lamp should flash. Any other results indicates the system has detected a
problem.
T.10 Lamp and Flas her Test
This test caesss all the uasntamps and the controlled
lamps to flash at the .sarne time. The controlled lamps blink, while the flashlamps cycle from
highest to lowest. Any other results indicates the system has detected a problem.
T .11 Display Test
ThiS test
autornatcany
checks every dot in the Dot Matrix Display.
A series of patterns appear in sequence. Each pattern turns On and Off a section of dots. Every
dot on the matrix display should be turned On and off during this test.
