T.4 Solenoid Test
The Solenoid Test has three modes, Repeat, Stop, and Run.
Only one solenoid should pulse at a
time.
The system has detected a problem If: more then one
solenoid pulses, a solenoid comes On and stays On or, during the Repeat and Run mode, no
solenoid
pulses.
Repeal
The
Repeat
mode pulses
a single
solenoid. Arter
entering
this test, Solenoid
1
shows
in
the display and the corresponding solenoid activates.
Press the Up or Down button to
cycle through the solenoids, one at a time. The same solenoid pulses until the Up or
Down bunon Is pressed. Either
press
the Escape button 10
return
to
the
Test Menu, or
press
the Enter
button to
move to
Ihe
next
mode.
Stopped -
The Stopped mode halts the Solenoid Test. Press Enter during the Repeat mode and
the Solenoid Test
steps.
No solenoids should be activated while the test is stopped.
Either press the Escape button to return to the Test Menu, or the Enter
button to move to
the next mode,
Running
The
Running
mode cycles through
the
solenoids automatically.
The display shows
Ihe
name and
number
of
the solenoid
ourrsritly
being pulsed.
T.5 Flasher
Test.
This
tests the ttasntarm part
of
the solenoid circuit
exclusively.
This, like the
Solenoid
Test,
has three modes: Repeat. Stop, and Run. During
this test, only
one
fJashlamp
circuit should
pulse at
a
time.
The
system
has
detected
a
problem
if
more
then one
circuit pulses,
a
cirCuit stays
On
or, during
the Repeat and Run mode, no olroult
pulses.
Repeal
The
Repeat mode pulses a single flashlamp. Alter ente~ing Ihis test, the
name
and
number of the first flashlamp circuit shows in
the
display and the corresponding bulb(s)
flash.
Press
the
Up
or Down button to cycle through aU01 the nasmamps circuits one at a
time.
The
same circuit
pulses
until
press the
Up
or
Down button
is pressed. Either press
the
Escape button to return to the Test Menu, or press the
Enter
button to advance to
the next mode,
Stopped -
The Stopped
mode halts the
Aasher Test.
No tlashlamp
circuit
should
be
active
durlng
this mode. Either press the Escape button to return
to
the Test Menu, or press the
Enter
button to
advance
to the next mode.
Running
The
Running
mode
cycles through the flashlamps automatically.
The display shows the
name- and
number of the lIashlamp circuit currently being pulsed, and the oorresponding
bulb(s)
flaSh.
T.6 Ge neral Illuminatio n Tes t
This tesl checks all 01 the G.eneral lIIumlnation
circuits. There are two modes of operation: Stop and Run.
Slopped -
Press the
Up or
Down buttons to
cycle
through the General Illumination Test manually. All
Illumination is tested
first.
followed by an individual circuit test. The circuit
name
and
number shows in the display while the corresponding lamps lights. If any other
results
occur the system has detected an error.
Running -
Press
the
Enter button any time during Stopped mode and the General lItumination. Test
cycles through automatically.
For each circuit shown in the display the corresponding
bulbs should light. If any
other
results occurs the
system
has detected a problem.
