GAME CONTROL LOCATIONS (Continued)
The CPU Diagnostic switch (SW 2) is the lower switch (of the two switches mounted on the left edge
of the CPU Board) near a large, socketed microprocessor chip. This switch initiates the Memory Chip
Test explained in the Diagnostic Procedures.
The Sound Diagnostic switch (SW 1) is the upper switch of the two mounted on the left edge of the
CPU Board. This switch initiates the Sound Section Test. Refer to the Diagnostic Procedures.
PINBALL GAME ASSEMBLY INSTRUCTIONS
1. Open the shipping container; remove all cartons, parts, and other items, and set them aside.
2. After finding the legs, install a leg leveller in the base of each leg. (See Figure 1, detailed view.)
Leg levellers and leg bolts are provided among the parts in the cash box.
3. Place the game cabinet on a support and attach the legs, using leg bolts.
4. Open the coin door and
remove
keys from clip on the door.
~.•
-
...
-
....••
--.
,
:
.
.
!~
,
.
, ,
\
SEE DETAIL
IIIEW
Detail Vlew-
Leg Leveler
Figure 1. Pinball Assembly, Playfield Pitch Ang Ie, and Leg Leveler Details.
5. Raise the hinged backbox upright and stabilize it into position, using the clamp on the back of the
cabinet and backbox. Unlock the backbox, and remove the back box glass, storing
it
carefully to
avoid scratches. Remove the shipping block holding the Insert Board. Unlatch the Insert Board
and open it, then lay the Speaker/Display Panel forward on the playfield cabinet. This allows
access to the bolt holes used for securing the backbox upright. Install the mounting bolts and flat
washers through the bottom holes of the backbox into the threaded fasteners in the cabinet to
secure the backbox.
6. Reach into the cabinet and backbox and check the mating of the interconnecting cables, match-
ing several wire colors at each connector. Ensure that all connections are properly secure.
©&!lUm@!Nl
Ensure that the interconnecting cables are free to move (not kinked or pinched). Be
careful not to damage wires at any stage of the assembly process.
