Cannon Assembly
p'n C-11641
Item Part No.
Description
Item Part No.
DescripUon
1 8-11640
Bracket Assembly
11 A-7438-1
Terminal Strip Assembly
2 23-6577
Plug Bumper
12 5070-06258-00 Diode, 1N4001, 1 A.
3 03-8089
Cannon Arm
13 4008-01017-04 Mach. Screw, 8-32 x
1/4
4
A-11769
Armature Link Assembly
14 4010-01066-06 Cap Screw, 10-32
x
3/8
5 02-4301
Cannon Arm Pin
15 4701-00004-00 Lockwasher, #10 split
6 10-395
Spring
16 4004-01003-10 Mach. Screw,
4-40
x
5/8
7 01-4813
Bracket, Coil Mounting
17
4700-00104-00 Flatwasher, .316 x .5 x .0598
8
AL-23-800
Coil Assembly
18 26-8712-31
Retaining Ring
9
A-10821
Coil Stop Bracket Assembly 19 03-7066
Coil Tubing
10 17-1067
Switch, Reworked
Miscellaneous
BIG GUNS
Parts
Part No.
Description
Part No.
Description
31-1002-557
Playlield, BIG GUNS
A-8552-557
Backglass Assembly, BIG GUNS
31-1357-557 8ackglass, BIG GUNS
31-1006-557
Plastics Set, BIG GUNS
31-1006A-557 Plastics Set, BIG GUNS
01-6571
Hinge Mtg Bracket, Insert Bd.
C-11762
8ackbox Interconnect Bel
Stop Bracket
latch - Insert Board
Insert Board (8ackbox)
Ribbon Cable, 20-conductor, g"
Ribbon Cable, 26-conductor, 27·
Playfield Mylar-
01-6652
01-6655
11-5S7-IN
5795-10937-09
5795-1 0938-27
03-7960-557
• available separately
BIG GUNS 49
