Lower Right Flipper Parts List
C-11626-R-3
-
ITEM PART NUMBER DESCRIPTION
ITEM PART NUMBER DESCRIPTION
•
•
1 HW-30018-6
Wire, 18 AWG, Blue
g)
B-10657-R
Flipper Crank Asay, R.
2 03-7520-2
Ty-Wrap, Nylon
1.) 01-8073-R
Flipper Crank, Right
•
3 20-6516
Speednut, Tinnerman
2.) 17-1037
Crank Washer
4 5045-12098-00
Capacitor, 2.2 J.1Fd,250V
3.) 4010-01066-18
Cap Screw, 10-32
5 RM-21-06
Sleeve, Vinyl (Cap. leads)
x 1-1/8, HCS
6 4010-01066-06
Cap Screw, 10-32 x
3/8,SH
4.) 4410-01127-00
Nut, 10-32 Hex Hd.
7 4701-00004-00
Lockwasher, #10 split
5.) 4700-00107-00
Washer,5/8 o.d. x
8 A-12111
Flipper Stop Assembly
13/641. d. x 12 gao
9 FL-11630
Flipper Coil (Red),
6.) 4701-00004-00
Loci<washer, #10 spilt
•
•
r-
RefertI Ncte 3)
7.) RM-23-06
Tubing, H. S.
1/4
DWP
10 4006-01017-04
MS, 6-32 x
1/4,
P-RH-S
14 23-6577
Bumper Plug
11 01-7695
Solenoid Bracket
15 03-7568
Flipper Bushing
12 10-376
Coli Plunger Spring
16 4006-01005-06
MS, 6-32 x
3/8,
P-PH
13 B-10655-R
Crank 'Link Assy, Right
17 4406-01117-00
Nut, 6-32 Hex
a)
02-4179
Link Spacer Bushing
18 C-11627-R
Flipper Base Assy, R.
b)
4010-01086-14
CS,10-32 x
718,SH
19 06-14G
Insulating Blade
e)
4700-00023-00
Washer,
5/8
o.d. x
20 4105-01019-10
Sh. Metal Screw.
•
13/64 i. d. x 16 gao
115x 518
d)
4701-00004-00
Lockwasher, #10 split
21 4701-00002-00
Lockwasher. #6 split
e)
4410-01132-00
Nut. 10-32 ESNA
22 23-6622
Tape. Double-sided
f)
A-10656**
Flipper Link Assembly
23 03-7811
End of Stroke (EOS) Sw
1.) 02-4219
Coli Plunger
2.) 20-9370-1
Spring Pin,
** - Also see separate diagram
5/32 dia. x
7/16
3.) 03-8050-1
Flipper Link
Lower Left Flipper Parts List
C-11626-L-3
(Parts listed replace same Items of
C-11626-R-3)
ITEM PART NUMBER DESCRIPTION
13 B-10655-L
g)
B-10657-L
1.) 01-8073-L
18 C-11627-L
Crank Unk Assembly, Left
Flipper Crank Assembly, Left
Flipper Crank, Left
Flipper Base Asay, Left
•
5-7
