Miscellaneous Hardware and Steel Assemblies
HOTSHOT (SOO17)
Part Number
Description
Quantity
Page No.
A-1446S·
Sleeve Weldment Ass'y
1
11-30
A-1479S·
Card Chute Assembly
1
11-38
C-10843
leg Assembly
4
2-2ab
01-10030
Cashbox Lock Bracket
1
9-OC
01-10208-1··
. Cover Plate
1
11-30b
01-10296·
Escutcheon
1
11-30
01-10297··
Chute Cover Plate
1
11-30b
01-10714
line Cord Cover
1
2-2Od
01-10797t
Support Bar, 18"
1
2-21
01-10865
Playfield Mounting Brkt
1
11-30a
01-10868-1
Hood Mounting Brkt, Right
1
11-30a
01-10868-2
Hood Mounting BrId, Left
1
11-30a
01-10869
Hood Retainer Bracket
2
11-30a
01-11027
Clip, Wood Deflector
2
11-30b
01-11042
Latch Bracket
2
11-30b
01-11168
Bal GuKie
1
11-30b
02-3179
Bar Space Support
1
11-30b
20-9347
Toggle Latch
2
10-26
·Used in conjunction with optional Card Dispenser.
Also see p. 5-2Sc.
··Used on games with no Card Dispenser Ass'y.
tSame as 01-4028 except for length.
