PC Lamp Boards and General Illumination Locations
SLUG FEST (60001)
and
SLUGFEST 2 (60021)
Playfield in Raised Position
Cabinet Interior
Cabinet (Front View)
Cabinet (Rear View) .
Item Part No.
Description
1
A-14380
3-Lamp PCB
fl
used)
2 A-14379
7-Lamp PCB (2 used)
3 A-14378
8-Lamp PCB (2 used)
0
4 A-14625
12-Lamp Display Panel
5
A-14537
1-Lampl1-FIash PCB (3 used)
6
A-14611
Inside Ught Panel Assembly
a)
A-14589
16-Lamp G.I. Ass'y
7 A-12224-1 1-L.amp PCB wlOiode (6 used)
8 A-12887
SockeV8ulb Ass'y (6 used)
Note: Schematics and Matrix tables are available
in Slugfest Operations Manual #16-60001-101.
