Video Game Kits
3044-K
Kit Parts List
Part No.
Description
Quantity
C-9214-5
Button Assembly. White
2 (See p. 10-18)
C-13234-3044-K Y-Unit CPU Assembly
1 (See p. 10-10, 10-n)
0-11581-3044
Audio Board Assembly
1 (See p. 10-14)
H-8866
Volume Control Cable 18"
1
H-12758
Sound Board Jumper Cable
1
H-13257
Sound PowerlSpeaker Cable
1
H-13411
Jamma Main Harness
1
16-3044- K-1
Kit Instruction Page
1
16-3044-K-101
Operations Manual
1
16-8587-795
FCC Warning Label
1
16-8587-825
FBI Warning Label
1
16-8587-892-1
Williams Kit Serial No. Label
1
16-8850-322
PCB Assembly Label
1
16-8903
Game Registration Card
1
20-9319-1
8-Way Joywtick. Red
4 (See p. 10-18)
20-9457
Button Holder wlSwitch
2 (See p. 10-18)
31-1480-3044-K Screened Control Panel Overlay
1
31-1481-3044-K Screened Marquee
1
31-1482-3044-K Decal Set
1
5014-12363-00
Volume Control Potentiometer
1
5795-1 0937-18
20-Pin Ribbon Cable
1
Hardware:
20-9222
Palnut 5/8"
2
4006-01 003-06
MS 6-32 x
3/8
P-PH-S
2
4308-01123-16B Bolt 8-32 x 1 CB
16
4406-01117 -00
Nut 6-32 Hex
2
4408-01128-00
Nut 8-32 Keps
16
4608-01 081 -11
H-F #8 x
11/16
PL-HWH
6
4608-01081-16
H-F #8 PL-HE-WH
7
4703-00007-00
LW #6 External
2
ELECTRONICS GAMEB.INC.
10-35
