Miscellaneous Parts
&
Hardware -
contd
Mounting/Support Brackets
Smash 19"
Smash 25"
Hit The Ice
Part No.
Description
3044-U 3044-U1
30003
Game and Part Quantity
01-7446
Speaker Panel Mig. Brkt.
2
01-9257
Spring Plate Mig. Brkt.
1
01-9408
Support Bracket - Right
1
01-9408-1
Support Bracket - Left
1
01-9893
Monitor Mounting Brkt.
4
01-9257
01-7446
01-9408 (Right shown)
01-9408-1 (Left)
01-9893
10-29
