Coin Door Assemblies
for Pinball & Shuffle Alley Games - contd
Hem Part Number
Deecrlptlon
auantlty
1 27-1038
Button Cover
20r3
2 27-1041-1-'-54 Price Panel
20r 3
3 27-1026-1-15 Coin Entry Plate
20r 3
4 27-1016
lock Assembly
1
5 27-1061-1
Coin Return - Bezel
1
6 27-1062
Coin Return Flap
1
7 27-1021
Button Housing - 2-slot
1
27-1022
Button Housing - 3-slot
1
8 27-1111
Interlock Switch
1
9 27-1006-1
Coin Door • 2-Slot
1
27-1007-1
Coin Door • 3-S1ot
1
10 27-1005
Coin Door Frame
1
11
27-1003
WC Screw. 6-32 x
3/16
4
12 27-1008
Diagnostic Switch
1
13 27-1101
WC Screw. 4-40 x 114
2
14 27-1102
Bracket. Diagnostic Switch 1
15 27-1037
Button
20r3
16 27-1078
WC Screw. 6-32 x 3J8
20r3
17 27-1039
Conical Spring
20r3
18 27-1079
SeH-tappingScrew,.s x
1/4
2
19 27-1077-1
Coinbox Cover
1
20 27-1066
Slam Switch
1
21 27-1067
WC Screw. 4-40 x 112
2
22 27-1017
Nut (key)
1
23 27-1012
locking Cam
1
24 27-1011
locking Arm
2
25 27-1020
Washer
1
26 27-1018
Star Washer
1
27 27-1019
WC Screw,
1/4-28
x
5/16
1
28 Not Used
·Parts of Item
30.
29 Not Used
30 27-1112
Coin Inlet Chute
20r3
31 27-1088
Cable Clamp
20r3
32 27-1025
Key Hook
1
33 27-1086
Washer.
IS
20r3
34 27-1078
we
Screw. 6-32 x 3/8
lor 2
27-1113
WC Screw, 6-32 x
7116
1
35 27-1079
SeN-tappingScrew,.s x 114 20r3
36 27-1084
lamp Socket
20r3
27-1085
lamp
20r3
37 27-1096
Self-tapping Screw. #5 x 3/8 20r3
38 27-1087
Mle Screw. 6-32 x 5/8
20r3
39 27-1082
Lever Arm
20r3
40 27-1097
Switch Cover
20r3
41 27-1091-1
Coin Accept Chute
20r3
42 27-1075
Wire Form (Small)
20r3
or
27-1093
Wire Form (large)
43 27-1094
WC Screw, 4-40 x 7/8
40r6
44
27-1087
Mle Screw. 6-32 x 5/8
40r6
45 27-1086
Washer. #6
40r6
46 27-1095
Nut. 4-40 ESNA
4016
47 27-1076-1
Coin Return Box
1
48 27-1078
WC Screw, 6-32 x 3/8
2
49 27-1092
Microswitch
20r3
O)f~e
ELECTRONICS GAMEB.INC.
9-5
