Pin Panel
Motor
Assembly
C-12096-1
Item Part Number
Descript ion
1 B-13091
2
B-13090
a)
4420-01119-00
b) 4700-00030-00
3 B-12095
4 RM-21-06
5 01-7543
6 14-7950
7 20-8712-25
8 20-8716-2
9
4700-00103-00
10 20-9246
11 4004-01003-10
12 4008-01017-04
13 4008-01074-08
14 5017-12180-00
15 5647-10915-00
Drive Link & Bushing Assy
Cam & Drive Post Assembly
Nut,
1/4-20
ESN
Flatwasher,
17/64
x
1/2
x
15ga.
Motor Mounting Bracket Assy
Tubing #18
Nut Plate, 4-40
Motor, 60
Hz,
48V
"E" Ring,
1/4"
Shaft
RoUpin,
3/32
x
5/8
Flatwasher,
17/64
x
112
x
28ga.
Fan Blade
Mach. Screw, 4-40 x
5/8
Mach. Screw, 8-32 x
1/4
Cap Screw, 8-32 x
1/2
Varistor, 1OOV,20J
Microswitch, E34-51 KL
