Page 69 - Williams RED Parts Catalog 16-9190-B

Printed Circuit Boards Located in the Backbox - cont'd
Drac Get Fish White
Part Number Description 50001 50004 50005 50018
Game and Part Quantity
A-12697-1 Power Driver Bd. Assembly 1 1 1 1
A-12738-Game# WPC Sound Board Assembly 1 1 1 1
A-12742-Game# WPC CPU Board Assembly 1 1 1 1
A-13088-2 Triac Driver Bd. Assembly 1
A-14039 Dot Matrix Controller Bd. 1 1 1 1
A-15309 2 - 10W Resistor PCB 1
A-15472 Fliptronic II Bd. Assembly 1 1 1 1
A-15761 Chase Light PCB Assembly 1
Lamp Boards
A-15565 5-Lamp PCB Assembly 1
A-15765 s-tamp PCB Assembly 1
A-16424 3-Flash Lamp PCB Ass'y 1
Notes: 1. Schematics for the above PC Boards and parts lists and matrix tables for the above Lamp
Boards are available in the individual game manuals listed on p. 7-0.
2. To locate a PCB in the Backbox, reter to the drawings for ea.chgame at the beginning of
this section.
