Ticket Dispenser Interface Board
A·14206
Part Number
Part Designation
Description
Qty.
5768-12737-00
PCB Ticket Dispenser
1
5791-12462-09
J1
Str. Sq. Lck. Header .100
1
5791-12462-15
J2
Str. Sq. Lck. Header .100
1
5641-09312-00
SW1
Sw P DPDT 100V SA
1
5641-12635-00
Q1
Transistor TIP102
1
5705-12464-00
Heat Sink
1
4004-01005-06
MS 4-40 x
3/8
P-PH
1
4404-01119-00
Lock Washer Nut 4-40
1
5012-1 0865-00
R8
Resister 50 10W 10%
1
5012-12529-00
R9
Resistor 100 10W 10%
1
5012-10860-00
R7
Resistor .270 5W 5%
1
5010-09314-00
R2, R3, R6, Al0
ResIstor 1.2K
1/4W 5%
3
5010·08998-00
R1
Resistor 2.2K
1/4W 5%
1
5010·09416-00
R5
Resistor 470K
1/4W 5%
1
5010-12465·00
R4
Resistor 2K
1/4W 5%
1
5043-08996-00
C1
0.1 MFD 50V AX Cr.
1
5040-09421-00
C2
100 MFD 25V +50/-10
1
5040-12466-00
C3
1000 MFO 50V AX
Elect.
1
5070-09054-00
02.03.04
Diode 1N4004 1.0A
3
5075-12467-00
01
IN5243B Zener 13V
1
5070-09045-00
05,06,07
Diode MR501 3.0A
3
5160-10269-00
.cs
Transistor 2N3904 NPN
1
5190-10270-00
02
Transistor 2N3906 PNP
1
8-Sm
ELECTRONICS GAMEB.INC.
