Printed Circuit Board Locations
----I
Upper Backbox, Front View
(Above Pin Panel)
Insert Board
Lower Backbox, Back View
(Behind Pin Panel)
Item Part Number
Description
1 A-12742-1 0002 WPC CPU Assembly
2 A-12738-10002
WPC Sound Board
3 A-14039
Dot Matrix Controller Assembly
4 A-12697-1
Power Driver Assembly
5 A-15052
Interconnect Board
6
5901-12784-00
Dot Matrix Display
Not shown:
A-130SS-2
Triac Driver Assembly
(Mtd. o~ Pin Panel)
A-14689-1
WPC Coin Door Interlace Board
(Mtd. on interior of Front Box)
0-12328
23-Lamp Board
(Mtd. on Hood Insert)
D-12327-L
5-Lamp Plfd PCB (Left)
D-12327-R
5-Lamp Plfd PCB (Right)
(Mtd. under Playfield)
Note:
Schematics for PCB's and matrix tables for Lamp Boards
are available in the individual Operations Manuals.
ELECTRONICS GAMEB.INC.
8-9a
