Page 636 - Williams RED Parts Catalog 16-9190-B

Specific Game Parts - cont'd
THE MACHINE (50002)
A-14358
Mini-Playfield Assembly
Item Part Number Description
1 31-1625 Screened Minl·Playfield
2 A·14318 Minj·Plfd Bait Guide Ass'y
3 03-8044-9 Bumper Post (25)
4 23-6535 Rubber Bumper (6)
5 23-6301 Rubber Ring, 3/4~ i.d.
6 4106-01019-08 SMS #6 x 112 P-RH·A (2S)
7 4006-01017·06 MS 6-32 x 3/8 RH-S (2)
8 4406·01119·00 Nut 6·32 ESN (2)
9 23-6300 Rubber Ring, 5/16- i.d.
10 23-6302 Rubber Ring, 1· i.d. (S)
11 02-4335-12 Standolf 8-32 Hex (2)
12 4700-00021-00 FW .203 x .437 x .032 (3)
13 4408-01119-00 Nut 8-32 ESN (4)
14 01-10126 Shield Bracket
15 03-6047-2 Spacer 3/8- (2)
16 4008-01003-12 MS 8-32 x 3/4" P-PH-S (2)
7-36 ELECTRONICS GAMEB.INC.
