Page 571 - Williams RED Parts Catalog 16-9190-B

Mini-Micro Switches & Associated Assemblies - cont'd
Switch Installed On Drac Get Fish White
Part Number Assembly Part No. 50001 50004 50005 50018
Game and Part Ouantity
5647-12693-08· A-11680 Switch Assembly 1 1 1 1
(See pp. 4-21 thru 4-22a)
5647-12693-11- A-15830 Lower to Upper Ramp 1
(See p. 3-3Oy)
5647-12693-13- A-1S837 Big Foot Ramp 1
(See p. 3-30z)
A-15838 Waterfall Ramp 1
(See p. 3-3Oza)
A-16253 Lower Left Ramp 1
(See p. 3-3Os)
5647-12693-14 A-16050 Motor Assembly 1
(See p. 5-70)
A-16271 Magnet Support Ass'y 1
(Mtd. under Playfleld to left
of Coil MagnetlScrew Ass'y)
5647-12693-1r A-15404 Reel Entry Ramp 1
(See p. 4-1On)
Note: For Mini-Micro Switches with wireforms. see Section 4.
·See p. 6-15 for drawings.
5647-12693--14
6-18a
