Page 568 - Williams RED Parts Catalog 16-9190-B

Mini-Micro Switches & Associated Assemblies - cont'd
Switch Installed On Mach Fun River Hurr Term2
Part Number Assembly Part No. 50002 50003 50007 50012 50013
Game and Part Quantity
5647-12073-06 * A-14624 Switch Ass'y 1
(See p. 5-47)
5647-12073-11* A~13894 Switch Ass'y 1
(See p. 3-30c)
5647-12073-13* A-12163 Switch Ass'y 2
(See pp. 3-30g & 3-30i)
5647-12073-21* A-13894 Lower Ramp 1
(See p. 3-30c)
A-13896 Upper Chute 2
(See p. 4-1Ob)
A-13897 Lower Chute I 1
(See p. 4-1Ob) I
8-13300-1 Sw Ass'y I 1
I (See p. 3-30h)
5647 -12073-36t 8-13850-1 SwiG ate 3
(See p. 3-30i)
5647-12073-43t A-13718 Head Ass'y 1
(See pp. 5-52 & 5-53)
5647 -12693-03t A-14754 Sw/8rkt Ass'y 1
(Used in conjunction with
Gun Ass'y; see p. 5-67)
5647 -12693-06 * A-14505 Platform/Kick 1
(See p. 5-66)
5647-12693-08* A-11680 Switch Ass'y 1 1 1 1 1
·See p. 6-15 for drawings.
tSee p, 6-19 for drawings.
Note: For Mini-Micro Switches with wireforms, see Section 4.
6-16 U)f~e ELECTRONICS GAMEB.INC.
