Unique Assemblies - cont'd
RIVERBOAT GAMBLER (50007)
Roulette Wheel Assembly
Ap14093-1
Item
Part Number
Description
1 01-8820-1
Molor Plate
2 8-12088
Motor
&
Connector Assembly
3 20-9570
Nut, M3 x .5, Hex
4 4701-00023-00 Lock Washer, #5 Split
5 0-12045
Motor Control Board
6
4006-01003-06 Mach. Screw, 6-32 x
3/8
7 03-8161
Plastic Wheel
8
4006-01 076-04 Set Screw, 6-32 x 114
9
16-8587-932
Label
10 31-2-50007-1
Decal
5-58
ELECTRONICS GAMEB.INC.
