Unique Assemblies - cont'd
WHIRLWIND (574)
Wheels Drive Assembly
0-13199
Item Part Number
Description
1
01-9406
Mounting Bracket
2 03-8346
115T Gear
3 03-8345
84T Gear
4 03-8344
72TGear
5
03-8343
Pinion
6
02-4419
Adjusting Screw (3)
7 02-4418
Shaft (3)
8 03-8347
Gland (3)
9 20-9610
Flange Bearing (6)
10 03-8363
Locking Nut (3)
11 31-1536-574-3
Small Decal
12 31-1536-574-2
Medium Decal
13 31-1536-574-1
Large Decal
14 14-7955
Motor
15 4008-01041-10
MS, 8-32 x 518, P-FLH (3)
16 4008-0 1017-08
MS, 8-32 x
112,
P-PH-S (3)
17 4108-01004-06
SMS, #8 x
3/8.
P-PH-ST (9)
18 4700-00016-00
FW, .187x.437x.053 (3)
19 20-9639
MS, Metric Screw (2)
20 4006-01076-04
S8, 6-32 x 114S (2)
21 16-8587-1000
Adjustment Label
