Unique Assemblies - confd
WHIRLWIND (574)
Ramp Lift Mechanism
8-11304
Item Part Number
Description
item Part Number
Description
1 A-11137
Lift Crank Assembly
15 03-7066
Coil Tubing
2 4406-01119-00
Nut, 6-32 ESN
16 4008-01021-07
MS, 8-32 x
7/16
3
A-8050
Plunger Assembly,
2-1/4-
17 4701-00003-00
LW, #8 Split
4 4700-00073-00
FW, 9132x
112
x 21 gao
18 4700-00089-00
FW,
11/64
x
7116
x 16
ga
5 12-6227
Hairpin Clip
19 B-11302
Lift Mechanism Brkt.
Assy.
6 10-128
Spring
20 A-6892
Frame & Eyelet Assembly
7 01-8-508-S
Coli Retaining Bracket
21 SM-2S-600-DC
Coil Assembly
8 400S-01017-06
MS, 6-32 x
318
22 A-11139
Armature Assembly
9 AE-26-1500
Coil Assembly
a)
A-8936
Armature Sub-Assy.
10 B-7572-1
Bracket & Stop Assembly
b)
01-8390
Lift Crank Lock
11 4004-01003-10
MS, 4-40 x
518
c)
4006-01003-03
MS, 6-32 x
3/16
12 5070-06258-00
Diode, 1N4001, 1.0A
23 10-363
Extension Spring
13 A-7438-1
Terminal Strip Assembly
24 12-6227
Hairpin Clip
14 5647-12001-00
Micro Switch
5-34
