Kicker Assemblies - cont'd
Playfield
(Shown for reference)
Kicker Arm (Slingshot) Assembly
A-14323
Item Part Number
1
2
3
4
5
6
7
01-10130
AE-23-800
01-8-508-T
03-7067
10-135
23-6420
4008-01017-05
Description
Kicker Mounting Bracket
Coil Assembly
Retainer Bracket
Coil Tubing
Coil Plunger Spring
Rubber Grommet
MS, 8-32
x
5/16
Gun Kicker Assembly
A-14S07
Item Part Number
1.
A-6306-2
2.
01-9595-2
3.
01-8-508- T
4.
10-135
5.
23-6420
6.
AE-24-900
7.
03-7067-5
8.
4008-01017-05
9.
01-10298
DescrIption
Bell Armature Assy.
Mounting Bracket Assy.
Solenoid Bracket
Solenoid Spring
Rubber Grommet
Coil Assembly
Coil Tubing
Mach. Screw, #8-32
x
5/16"
Mounting Bracket
Kickback Asssembly - Right
A-14525
Item
Part
Number
1.
A-6306-2
2.
A-14526
3.
01-8-508-T
4.
10-135
5.
23-6420
6.
AE-23-800
7.
03-7067-5
8.
4008-01017-05
ELECTRONICS GAMEB.INC.
Description
Bell Armature Assy.
Mounting Bracket Assy.
Solenoid Bracket
Solenoid Spring
Rubber Grommet
Coil Assembly
Coil Tubing
Mach. Screw, #8-32 x 5/16"
