Jet Bumper Assemblies - confd
B•.9414
Item Part Number
Description
1 A-4754
Bumper Ring Assembly
a)
01-2161
Rebound Ring
b)
02-2134E
Rod Connector (2)
~
2 03-6009-AS
Bumper Base, White
3
03-6035-5
Bumper Wafer, White
4
03-7443-5
Bumper Body, White
5
10-7
Jet Bumper Spring
6
A-11199
Socket
&
Bulb
Assy.
a)
24-8768
#555 Bulb, 6.3V, .25A
b)
24-SnS
Wedge Socket
7 03-S254-9
Jet Bumper Cap, Tr. Red
B·9414-1
(Part listed replaces same
item
of 8-9414)
Item Part Number
Desaiption
3 03-6035-1
Bumper Wafer, Blue
8-9414-2
(Parts listed replace same items of
8-9414)
Item Part Number
Description
3 03-6035-5
7 03-8254-16
Bumper Wafer, Yellow
Jet Bumper cap. Tr. Yellow
8-9414-3
(Part listed replaces same item of B-9414)
Item Part Number
Description
3
03-6035-4
Bumper Wafer, Red
5-16
