Page 425 - Williams RED Parts Catalog 16-9190-B

Flipper Assemblies
Diner Whirl BlCats Roller
Part Number Description 571 574 575 576
Game and Part Quantity
- _-.-_---- -_ ..._-
C-11626-L-3 Lower Left Flipper 1 1 1
C-11626-R-3 lower Right Flipper 1 1 1
Upper Right Flipper 1
C-13174-L Lower Left Flipper 1 I
C-13174-R lower Right Ripper 1 !
- ---- -- - -~s--.-_! _
C-13830 Upper Right Ripper ! 1
Mach Fun River Hurr Term2
Part Number Description 50002 50003 50007 50012 50013
Game and Part Number
A-15318-L Lower left Flipper 1
A-15318-R Lower Right Ripper 1
C-13174-L Lower Left Flipper 1 1 1 *
C-13174-L-1 Upper left Flipper 1
C-13174-L-3 ,Lower Left Flipper 1
C-13174-R Lower Right Flipper 1 1 1 ..
C-13174-R-3 Lower Right Flipper 1
"Used on the first 250 games manufactured.
Drac Get Fish White
Part Number Description 50001 50004 50005 50018
Game and Part Quantity
A-1S20S-L-2 lower Left Flipper Ass'y 1 1
A-1S205-L-4 Lower Left Flipper Ass'y 1 1
A-1S205-_R Upper Right Flipper Ass'y 1
A-15205-R-2 Lower Right Flipper Ass'y 1 1 1
A-1S205-R-4 Lower Right Flipper Ass'y 1
A-15843 Mini-Playfield Flipper Ass'y 1
5-11
